Description
msi foot pedal Minn Kota Ultrex 36v Foot Pedal Assembly MSI 2992157Part Number: 2992157 Minn Kota Ultrex 36v Foot Pedal Assembly MSI Complete foot pedal assembly for Minn Kota Ultrex 112 models with built in MEGA Side Imaging Fits the following Minn Kota trolling motor models: Minn Kota Ultrex 112 BT models with built in MEGA Side Imaging from 2017 Present Minn Kota Ultrex 112 models with US2 and MEGA Down Imaging will need p n 2992156 THIS PART IS SPECIAL ORDER ONLY. PLEASE ALLOW 3 5 BUSINESS DAYS BEFORE RECEIVING A
Part Number: 2992157
Minn Kota Ultrex 36v Foot Pedal Assembly MSI
Complete foot pedal assembly for Minn Kota Ultrex 112 models with built in MEGA Side Imaging
Fits the following Minn Kota trolling motor models:
- Minn Kota Ultrex 112 BT models with built in MEGA Side Imaging from 2017 - Present
Minn Kota Ultrex 112 models with US2 and MEGA Down Imaging will need p/n 2992156
THIS PART IS SPECIAL ORDER ONLY. PLEASE ALLOW 3-5 BUSINESS DAYS BEFORE RECEIVING A SHIPPING NOTIFICATION.
Parts included with this assembly:
| Quantity | Part Number (Old Part Numbers) | Part Description |
| 1 | 2773705 (2993705) | Push Button/Magnet Assembly |
| 1 | 2887313 (2307313) | Ferrite Bead |
| 1 | 2302732 | Foot Pedal Spring SS |
| 1 | 2260810 | Reed Sensor Clip |
| 1 | 2263000 | E Clip |
| 1 | 2994451 | Foot Pedal w/ Magnet |
| 1 | 2884023 (2294025, 2294027) | Steering Sensor Control Board |
| 2 | 2294410 | Sensor Actuator |
| 1 | 2294420 | Actuator Carrier |
| 1 | 2294430 | Carrier Bracket |
| 1 | 2292300 | Cable Drum Pulley |
| 1 | 2293401 | Set Screw SS, 1/4 - 20 x 1/2 |
| 1 | 2293720 | SpotLock Button |
| 1 | 2293730 | AutoPilot Button |
| 1 | 2263710 | Prop Button |
| 4 | 2292700 | Button Spring |
| 1 | 2295625 | Indicator Lights Decal |
| 4 | 2373440 | Screw SS, #4 - 24 x 1/4 |
| 1 | 2260511 | Pivot Pin |
| 1 | 2774018 (2044022) | On/Off Power Switch |
| 1 | 2266413 | Tension Screw Plate |
| 1 | 2262301 | Pulley |
| 1 | 2993715 | Prop Sensor Arm w/ Magnet |
| 1 | 2266401 | Pulley Cover |
| 1 | 2291920 | Bottom Plate |
| 1 | 2774061V (2274061, 2294061, 2774061) | Ultrex 36v Control Board |
| 4 | 2265126 | Bumper Pad |
| 4 | 2378600 | Aluminum Pop Rivet, 3/16 x 3/4 |
| 2 | 2223455 | Screw, #10 - 32 x 1/2" |
| 1 | 2993735 | AutoPilot Sensor Arm w/ Magnet |
| 1 | 2993725 | SpotLock Sensor Arm w/ Magnet |
| 1 | 2994500 | Foot Pedal Base w/ Pin |
| 1 | 2365107 | Insulating Pad |
| 1 | 2263210 | Conduit Adjustment Bracket |
| 1 | 2263140 | Nylock Keeper |
| 1 | 2263466 | Screw SS, 1/4 -20 x 2" |
| 1 | 2265115 | Foot Pedal Base Boot |
| 1 | 2296410 | Coil Cord Cover |
| 1 | 2291910 | Cable Anchor Bracket |
| 2 | 2373450 | Screw SS, #8 - 18 x 3/8" |
| 2 | 2323406 | Screw SS, #10 - 24 x .50" |
| 1 | 2296400 | Wrap Drum Cover |
| 2 | 2293403 | Screw SS< #6 - 32 x .625" |
| 1 | 2296405 | Motor Connection Cover |
| 1 | 2291201 | Coil Cord Assembly MSI |
| 1 | 2290100 | Speed Control Knob |
| 1 | 2294400 | Lower Rocker |
| 1 | 2297505 | 5' Right Cable Assembly |
| 1 | 2297515 | 5' Left Cable Assembly |
| 1 | 2297411 | Long Wire Harness |
| 1 | 2265430 | 5' Cable Jacket |
| 2 | 3393450 | Screw, #6 - 19 x .75" |
| 18 | 2372100 (9370070) | Screw SS, #8 - 18 x 5/8" |
| 2 | 2261714 | Washer SS, #8 |
| 4 | 2332103 | Screw SS, #6 - 20 x 3/8" |
| 1 | 2052510 | Nylon Cable Clamp, 3/16" |
| 1 | 2290840 | Nylon Cable Clamp, 1/4" |
| 2 | 2301310 | Screw SS, #8 - 18 x 1/2" |
| 1 | 2298800 (2026300) | Wire Loom, 1/4" x 4" |
| 3 | 2256300 (2026300, 2056300) | Tie Wrap, 5.5" |
| 1 | 2290605 | Battery Leadwire |
| 1 | 3391722 | Flat Washer, 7/16" |
| 1 | 2296300 | Panel Mount Tie Wrap |
Not sure if this part will fit your Minn Kota trolling motor? Parts Diagrams
